MIKROTIK HAP AC LITE

Përshkrimi

MIKROTIK HAP AC LITE Specifications Details Product code RB952Ui-5ac2nD Architecture MIPSBE CPU QCA9531 CPU core count 1 CPU nominal frequency 650 MHz Switch chip model QCA9531 Dimensions 113 x 89 x 28mm RouterOS license 4 Operating System RouterOS Size of RAM 64 MB Storage size 16 MB Storage type FLASH MTBF Approximately 100’000 hours at 25C Tested ambient temperature -30°C to 70°C Wireless capabilities Details Wireless 2.4 GHz Max data rate 300 Mbit/s Wireless 2.4 GHz number of chains 2 Wireless 2.4 GHz standards 802.11b/g/n Antenna gain dBi for 2.4 GHz 1.5 Wireless 2.4 GHz chip model QCA9531 Wireless 2.4 GHz generation Wi-Fi 4 Wireless 5 GHz Max data rate 433 Mbit/s Wireless 5 GHz number of chains 1 Wireless 5 GHz standards 802.11a/n/ac Antenna gain dBi for 5 GHz 2 Wireless 5 GHz chip model QCA9887 Wireless 5 GHz generation Wi-Fi 5 WiFi speed AC750 Ethernet Details 10/100 Ethernet ports 5 Peripherals Details Number of USB ports 1 USB Power Reset Yes USB slot type USB type A Max USB current (A) 1 Powering Details Number of DC inputs 2 (DC jack, PoE-IN) DC jack input Voltage 10-28 V Max power consumption 20 W Max power consumption without attachments 8 W Cooling type Passive PoE in Passive PoE PoE in input Voltage 10-28 V PoE-out Details PoE-out ports Ether5 PoE out Passive PoE Max out per port output (input 18-30 V) 500 mA Max total out (A) 500 mA Certification & Approvals Details Certification CE, FCC, IC, EAC, ROHS IP IP20 Wireless specifications 2.4 GHz Transmit (dBm) Receive Sensitivity 1MBit/s 22 -96 11MBit/s 22 -89 6MBit/s 20 -93 54MBit/s 18 -74 MCS0 20 -93 MCS7 16 -71 5 GHz Transmit (dBm) Receive Sensitivity 6MBit/s 23 -93 54MBit/s 20 -75 MCS0 23 -93 MCS7 19 -71 MCS9 16 -63
