MBO GIGABYTE B760 DS3H AX

Përshkrimi

MBO GIGABYTE B760 DS3H AX • Intel Socket LGA 1700：Support 13th and 12th Gen Series Processors • Unparalleled Performance：Hybrid 8+2+1 Phases Digital VRM Solution • Dual Channel DDR5：4*DIMMs XMP Memory Module Support • Next Generation Storage：2*PCIe 4.0 x4 M.2 Connectors • EZ-Latch：PCIe 4.0×16 Slot with Quick Release Design • Fast Networks：GbE LAN & Wi-Fi 6E 802.11ax • Extended Connectivity：Rear USB-C 20Gb/s, DP, HDMI • Smart Fan 6：Features Multiple Temperature Sensors, Hybrid Fan Headers with FAN STOP • Q-Flash Plus：Update BIOS Without Installing the CPU, Memory and Graphics Card SPECS • CPU • LGA1700 socket: Support for the 13th and 12th Generation Intel Core, Pentium Gold and Celeron Processors • L3 cache varies with CPU (Please refer “CPU Support List” for more information.) • Chipset • Intel B760 Express Chipset • Memory • Support for DDR5 7600(O.C.) /7400(O.C.) /7200(O.C.) /7000(O.C.) /6800(O.C.) /6600(O.C.) / 6400(O.C.) / 6200(O.C.) / 6000(O.C.) / 5800(O.C.) / 5600(O.C.) / 5400(O.C.) / 5200(O.C.) / 4800 / 4000 MT/s memory modules • 4 x DDR5 DIMM sockets supporting up to 192 GB (48 GB single DIMM capacity) of system memory • Dual channel memory architecture • Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode) • Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules • Support for Extreme Memory Profile (XMP) memory modules (The CPU and memory configuration may affect the supported memory types, data rate (speed), and number of DRAM modules, please refer to “Memory Support List” for more information.) • Onboard Graphics Integrated Graphics Processor-Intel HD Graphics support: • 1 x HDMI port, supporting a maximum resolution of 4096×2160@60 Hz * Support for HDMI 2.0 version and HDCP 2.3. • 1 x DisplayPort, supporting a maximum resolution of 4096×2304@60 Hz * Support for DisplayPort 1.2 version and HDCP 2.3 (Graphics specifications may vary depending on CPU support.) • Audio • Realtek Audio CODEC • High Definition Audio • 2/4/5.1/7.1-channel * You can change the functionality of an audio jack using the audio software. To configure 7.1-channel audio, access the audio software for audio settings. • Support for S/PDIF Out SPECS • LAN • Realtek GbE LAN chip (1 Gbps/100 Mbps) • Wireless Communication module Intel Wi-Fi 6E AX210 (PCB rev. 1.0) • WIFI a, b, g, n, ac, ax, supporting 2.4/5/6 GHz carrier frequency bands • BLUETOOTH 5.3 • Support for 11ax 160MHz wireless standard and up to 2.4 Gbps data rate Intel Wi-Fi 6E AX211 (PCB rev. 1.1) • WIFI a, b, g, n, ac, ax, supporting 2.4/5/6 GHz carrier frequency bands • BLUETOOTH 5.3 • Support for 11ax 160MHz wireless standard and up to 2.4 Gbps data rate Realtek Wi-Fi 6E RTL8852CE (PCB rev. 1.2) • WIFI a, b, g, n, ac, ax, supporting 2.4/5/6 GHz carrier frequency bands • BLUETOOTH 5.3 • Support for 11ax 160MHz wireless standard and up to 2.4 Gbps data rate (Actual data rate may vary depending on environment and equipment.) SPECS • Expansion Slots CPU: • 1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x16 (PCIEX16) * For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot. Chipset: • 4 x PCI Express x16 slots, supporting PCIe 3.0 and running at x1 (PCIEX1_1, PCIEX1_3~PCIEX1_5) • Storage Interface CPU: • 1 x M.2 connector (Socket 3, M key, type 22110/2280 PCIe 4.0 x4/x2 SSD support) (M2A_CPU) Chipset: • 1 x M.2 connector (Socket 3, M key, type 2280 PCIe 4.0 x4/x2 SSD support) (M2P_SB) • 4 x SATA 6Gb/s connectors RAID 0, RAID 1, RAID 5, and RAID 10 support for SATA storage devices • USB Chipset: • 1 x USB Type-C port on the back panel, with USB 3.2 Gen 2×2 support • 1 x USB Type-C port with USB 3.2 Gen 1 support, available through the internal USB header • 1 x USB 3.2 Gen 2 Type-A port (red) on the back panel • 2 x USB 3.2 Gen 1 ports available through the internal USB header • 4 x USB 2.0/1.1 ports on the back panel Chipset+2 USB 2.0 Hubs: • 4 x USB 2.0/1.1 ports available through the internal USB headers SPECS • Internal I/O Connectors • 1 x 24-pin ATX main power connector • 1 x 8-pin ATX 12V power connector • 1 x CPU fan header • 1 x CPU fan/water cooling pump header • 3 x system fan headers • 1 x system fan/water cooling pump header • 2 x addressable LED strip headers • 2 x RGB LED strip headers • 2 x M.2 Socket 3 connectors • 4 x SATA 6Gb/s connectors • 1 x front panel header • 1 x front panel audio header • 1 x S/PDIF Out header • 1 x USB Type-C header, with USB 3.2 Gen 1 support • 1 x USB 3.2 Gen 1 header • 2 x USB 2.0/1.1 headers • 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only) • 1 x serial port header • 1 x Q-Flash Plus button • 1 x reset button • 1 x reset jumper • 1 x Clear CMOS jumper • Back Panel Connectors • 1 x PS/2 keyboard/mouse port • 2 x SMA antenna connectors (2T2R) •…
